MiniQ AMP
iPad / Musique
MiniQ AMP is a high-performance portable integrated system, which is a small system integrated solution integrating digital mixer + audio processor + power amplifier. Provides 8 channels of digital mixing console solutions including: 3 channels of MIC/LINE input + 1 channel of LINE input of 1/4" interface, 4 channels of switchable: XLR / RCA, Bluetooth, USB L/R channel input; configuration A 1/4" headphone jack with adjustable gain is provided for AUX/Monitor output. It can switch to drive the power amplifier output of 2.0 / 2.1 system. Under 2.0 output 4Ω load, it has 4x500w power output, and under 2.1 output 4Ω load, it has 2x500W+1000w power output. Built-in powerful FIR audio processor, compact body and powerful built-in DSP make this amplifier portable while taking into account all kinds of small fixed installation and mobile performance markets, it can be completed independently in front of speakers in small sound reinforcement scenarios It only needs to connect the audio source signal to the MiniQ to complete the work of mixing, frequency division and driving speakers in one step.
MiniQ uses a powerful Marani DSP, both DSP and AD/DA run at 96KHz sampling rate, and built-in up to 1024Taps FIR filter (with iFIR Wizard), effects, feedback cancellation, automatic mixing and a series of complex sound processing functions , providing an integrated complete crossover solution for speakers. Each input/output channel is equipped with gain/PEQ/compression/delay/polarity, etc. The output channel is also equipped with peak limiter and hard limiter to better protect the speakers. MiniQ is equipped with WIFI and TCP/IP, and PC can monitor or control equipment online through local area network.
Feature
1. It is a small system integrated solution integrating digital mixer, audio processor and power amplifier, with optional switching to drive 2.0/2.1 channel system.
2. The built-in MARANI DSP runs at a sampling rate of 96k. The new circuit design makes the MiniQ AMP have the advantages of soft sound, powerful self-protection function, low noise and high efficiency.
3. Equipped with a series of complex sound processing functions such as FIR filters, automatic mixing, feedback cancellation, effects and so on
4. A new "zero-delay" hard limiter has been added to better protect the speaker unit.
5. The fourth-generation iFIR wizard V4.0 plug-in supports automatic measurement/import of
third-party measurement data, automatic calculation and correction of amplitude frequency response and phase frequency response curves, and generation of FIR coefficients for fast
insertion into equipment.
6. 2 DCA groups, 4 mute groups and 4 Solo group controls
7. You can join the local area network or WiFi hotspot to establish a local area network through
WiFi/Tcp/ip, providing more convenient online control.
8. The built-in dynamic loudness booster works by adaptively boosting the ultra-low and ultra-high frequency bands according to the equal loudness curve of the human ear.
