ITS Calculator

iOS Universel / Productivité

Gratuit

Obtenir sur l'App Store

ITS calculator includes tools to calculate Conduit Fill, Cable Tray Fill, MUTOA Cord length, and Fiber Budget Loss calculation

Conduit Fill :
To calculate conduit fill ratio of given standard trade size and cable diameter. Optional add derating of 15% per bend for a maximum allowed 2 between pull box.

Cable Tray Fill:
Calculate three different cable fill ratio (40%, 50%, and 60%) using cable tray width and height.

MUTOA Cord length:
Calculate maximum allowed patch cord length at TR room side and MUTOA (Multi User Telecommunication Outlet Assembly) side for solid, 24AWG and 26AWG cords by providing horizontal permanent link length.

Fiber Budget Loss:
Provides total loss at both wavelengths for both Mulitmode and Singlemode fiber by using maximum dB/km value set by TIA 568-C.3. Save typical value and load to calculate the custom budget value of a link. Based on link budget loss Application Support tab provides details of supported applications

En voir plus...

Quoi de neuf dans la dernière version ?

Bugs fixed, Performance improvements
