Brain / iKon / Xbar / TracX
iOS Universel / Divertissement
Application pour tablettes et téléphones iOS. Permet de configurer vos modules flybarless Brain/Ikon/Xbar/Tracx via Bluetooth.
Cette application fonctionne nativement avec les modules MSH ayant la fonction Bluetooth intégrée. Les autres modules nécessitent un module Bluetooth externe MSH pour iOS, vendu séparément.
Pour être pleinement fonctionnelle, l’application nécessite que la dernière version du firmware soit installée dans le module. Si votre appareil dispose d’un accès internet, l’application vous avertira lorsqu’une nouvelle version du firmware est disponible.
Les produits MSH peuvent être achetés auprès des revendeurs officiels MSH.
Quoi de neuf dans la dernière version ?
• ESC Events: If errors are transmitted from the ESC telemetry while the flight control unit is still initializing, they are saved and recorded in the flight control unit's EVENTS immediately after initialization is completed
• The ‘Min V to go’ function now holds the motor in place even when YGE ESCs are used, which unlike all other ESCs, when programmed to work with Futaba brings the minimum value of throttle pulses to switch off the motor below 1000uS (to 950uS)
• JR X-Bus Protocol A: handle unforeseen situations where users incorrectly program transmitters with a throttle signal below -5% and/or above +105%
• The “Configure Bluetooth module” function to initialize and change PIN and NAME of Bluetooth modules now works with more model of Bluetooth modules (the total time the two LEDs both stays lit indicating the sending of the various initialization commands to BT module is now ~12 seconds)
• Added QOS for FrSky receivers that can set the serial output connected to CH3 to “SBUS out” mode (EG: TD-RXX)
• Now with Graupner ‘Basic telemetry’ (RPM for Nitro, Gasser, Turbine models) is also simulated with ‘HoTT Sensor Kind’ set to ESC (that is the default sensor kind) in case ELEC and GEN are already used by external sensors connected to the telemetry bus
• Improved in DIAGNOSTIC the resolution of vertical scale of VSAT parameter (renamed to “SAT Voltage”)
• Following the appearance of 12V servos on the market, event 161 (Servo Voltage greater than...) now occurs when the voltage exceeds 13V.
• In COUNTERS added ‘One Way Bearing’ to the list of components whose time-of-use is to be calculated
• For receivers that can be programmed by the transmitters to use different protocols (EG: F.Port/F.Bus, Crossfire, etc.) the QOS values (Fades, Frame losses, Holds, Frame Rate, etc.) are reset to zero even when changing communication protocols without cycling the power supply.
• Added inside “Brain2OpenTX-EdgeTX.zip” the new folder “_HOTT_MULTI”
• New version of "Brain2_FwdPrg.lua" (inside the folder “_SRXL2_MULTI” in the “Brain2OpenTX-EdgeTX.zip”)
• Updated inside “Brain2OpenTX-EdgeTX.zip” the configuration example file “TX16S_Brain2.yml” for working also with Nitro / Gasser / Turbine models
• New version of “Brain2OpenTX-EdgeTX.zip”
• New version of “Brain2crossfire.zip”
• New version of “Ethos_Integration.zip”
• New version of “Brain2Jeti.zip”
• Updated Spektrum Integration
• Updated Graupner Integration
• New version of the embedded document “README_for_ESC_datas_log_and_telemetry.pdf”
• New version of the embedded document “README_for_OpenTX_EdgeTX_integration_for_BRAIN.pdf”
• Added some instructions, changed some instructions, some tooltip, some labels in the app and also in the Integrations and also in the Events to be clearer
• Revised French instructions
• Improvements / optimization / compression / size reduction / code speedup
